| DIMENSIONS | |
| Overall length | 3,575 mm |
| Overall width | 980/1,350 mm |
| Overall width of superstructure | 980 mm |
| Overall height above cab | 2,410 mm |
| Rear length | 920 mm |
| Track width | 750/1,120 mm |
| Landing gear length | 1,585 mm |
| Landing gear width (dozer blade) | 980/1,350 mm |
| Blade height | 270 mm |
| Track link width | 230 mm |
| Tail swing radius | 920 mm |
| Distance between track wheel and guide wheel (center) | 1,220 mm |
| Boom length | 1,810 mm |
| Arm length | 1,130 mm |
| Bucket capacity | 0.04 cubic meters |
| WORKING RANGE | |
| Max. ground level range | 4,000 mm |
| Max. excavation depth | 2,360 mm |
| Max. vertical range | 3,665 mm |
| Max. dumping height | 2,635 mm |
| Minute radius of gyration | 1,705 mm |
| Max. excavation depth, vertical wall | 2,215 mm |
| Min. working machine height. radius of gyration | 2,745 mm |
| WEIGHT | |
| Operating mass | 1,925 kg |
| ENGINE | |
| Model | Yanmar 3TNV80F |
| Rated power | 14,6 kW |
| Max. torque | 64,7 Nm/1,800 ft/min |
| Shift | 1267 cubic cm |
| HYDRAULIC SYSTEM | |
| Main pump | 1 Adjustable axial piston pump |
| Maximum oil flow | 40 l/min |
| Travel drive | 2 Adjustable axial piston pump |
| Rotary gear | 1 Adjustable axial piston pump |
| RELIEF VALVE SETTING | |
| Boom circuit | 270 bar |
| Slewing circuit | 162 Bar |
| Drive circuit | 270 bar |
| Pilot control circuit | 35 bar |
| PERFORMANCE | |
| Swing speed | 10 turns |
| Max. ground speed | 4 km/h faster, 2.2 km/h slower |
| Max. traction | 15.6kN |
| Climbing ability | 30° |
| ISO bucket separation force | 15.2 kN |
| ISO arm tear | 9.2kN |
| SERVICE REFILL CAPACITIES | |
| Tank | 23 l |
| Engine coolant | 3.8 l |
| Engine oil | 2 l |
| Travel drive (each side) | 0.4 l |
| Hydraulic tank | 21 l |
